SL4 display panel
| 5144726 | |
| Nuovo | |
| Computed Tomography (CT) | |
| GE HealthCare | |
| GE HealthCare | |
| N/A | |
Aggiungi a lista dei desideri
Accedi e aggiungi al carrello
Selezionare data
Approvazione seconda opinione necessaria
Immettere il numero approvazione e inviare per aggiungere articolo(i) al carrello.
Numero approvazione
Please enter approval number
OR
Non conosci il tuo numero approvazione? Chiamare il numero 800-437-1171
Immettere opz 1 per le prime tre richieste e rendere disponibile l’ID sistema.
Aggiungendo uno o più articoli al carrello e inviando l’ordine senza il
numero di approvazione, si verrà richiamati da GE prima della conferma dell’ordine
per la spedizione.
Approvazione seconda opinione necessaria
Select your approver's name and submit to add item(s) to your cart
Approver Name
Please Select Approver Name
OR
Don't know your approval number? Call 800-437-1171
Enter opt 1 for the first three prompts, and have your System ID available.
If you add item(s) to cart and submit your order without
selecting an approver, GE will contact you before your order
can be confirmed for shipment.
Informazioni sul prodotto
The SL4 Display Panel is used in Gantry User Interface (GUIF) System. The panel also has 6 LED indicators: Cardiac Indicator, Alignment Lights, Cradle Unlatched, Respiratory Indicator, Interference Indicator and X-Ray On. The two Breathing Light Assemblies on the front and rear Gantry covers and one X-Display Assembly on the rear are driven directly by the Display Panel. The assembly comes with a 15 and a 9 pin D type connector for the interfaces. The Display Panel will drive three other smaller display devices also located on the Gantry covers. The Display Panel will be able to display numeric information for the user through seven segment displays. It has three numeric display blanks: Tilt Position with 4 seven segments, Elevation Position with 4 seven segments and Cradle Position with 7 seven segments.. This Assembly can be used with Brightspeed Edge, Brightspeed Excel, Brightspeed Elite and Discovery 670 systems.
